High Melting Point Corrosion Resistant Non-Magnetic Nichrome Electric Resistance Wire for Heating Elements

Thông tin chi tiết sản phẩm

Nguồn gốc: TRUNG QUỐC

Hàng hiệu: Tankii

Số mô hình: NiCr 80/20

Điều khoản thanh toán & vận chuyển

Số lượng đặt hàng tối thiểu: 20kg

Giá bán: usd+25+kg

chi tiết đóng gói: Hộp giấy+xuất khẩu pallet gỗ

Thời gian giao hàng: 20 ngày

Điều khoản thanh toán: L/C, D/A, D/P, T/T, Liên minh phương Tây

Khả năng cung cấp: 100000TẤN/THÁNG

Nhận giá tốt nhất
Liên hệ ngay
Thông số kỹ thuật
Làm nổi bật:

nichrome resistance wire

,

tankii electric heating wire

,

nicr alloy resistance wire

Mô tả
High Melting Point Corrosion Resistant Non-Magnetic Nichrome Electric Resistance Wire for Heating Elements

Basic Info.

Model NO.
Ni80Cr20, Ni60Cr15, Ni35Cr20
shipment
by air, by sea
Transport Package
Spool, Paper Carton, Wooden Case
Specification
RoHS, ISO 9001
Trademark
TANKII
Origin
China
HS Code
75052200
Production Capacity
200 Tons/Month

Packaging & Delivery

Package Size
11.00cm * 11.00cm * 1.00cm
Package Gross Weight
11.000kg

Product Description

Nichrome Electric Resistance Wire and Strip

Nichrome Wire/Strip/Tape/Ribbon/Rod/Bar grade NiCr 80/20, NiCr 60/15, NiCr 35/20, NiCr 30/20

Nichrome Wire/Strip/Tape/Ribbon/Rod/Bar

NCHW1, NCHW2, Resistohm 80, Resistohm 60, Resistohm 40, Ni80Cr20, Ni60Cr15, Ni35Cr20, Nichrome 80/20, Nichrome 60/16

Shape: Flat Wire Thickness 0.02~1mm Width 0.6~5mm

Round Wire 0.025mm~16mm,

Strip,Sheet Coil: Thickness 0.005~3mm Width 1~300mm

We also can enameled the wire or process into spiral shape for you.Or make one oxidized cellar for your wire, strip or heating element.

Producer: Shanghai Tankii Alloy Material Co., Ltd.

Nichrome is a non-magnetic alloy of nickel, chromium, and often iron, usually used as a resistance wire. Patented in 1905, it is the oldest documented form of resistance heating alloy. A common alloy is 80% nickel and 20% chromium, by mass, but there are many others to accommodate various applications. It is silvery-grey in colour, is corrosion-resistant, and has a high melting point of about 1400 °C (2552 °F). Due to its relatively high electrical resistivity and resistance to oxidation at high temperatures, it is widely used in electric heating elements, such as in hair dryers, electric ovens, soldering iron, toasters, and even electronic cigarettes. Typically, Nichrome is wound in coils to a certain electrical resistance, and current is passed through to produce heat.

Chemical Composition and Main Properties of Nichrome
Properties Grade NiCr 80/20 NiCr 70/30 NiCr 60/15 NiCr 35/20 NiCr 30/20
Main Chemical Composition Ni Balance Balance 55.0-61.0 34.0-37.0 30.0-34.0
Cr 20.0-23.0 28.0-31.0 15.0-18.0 18.0-21.0 18.0-21.0
Fe ≤ 1.0 ≤ 1.0 Balance Balance Balance
Max Continuous Service Temperature(oC) 1200 1250 1150 1100 1100
Resisivity 20oC (Ω mm2/m) 1.09 1.18 1.12 1.04 1.04
Density (g/cm3) 8.4 8.1 8.2 7.9 7.9
Thermal Conductivity(KJ/m@ h@ oC) 60.3 45.2 45.2 43.8 43.8
Coefficient of Thermal Expansion(α × 10-6/oC) 18 17 17 19 19
Melting Point( Ω ) 1400 1380 1390 1390 1390
Elongation(%) > 20 > 20 > 20 > 20 > 20
Micrographic Structure austenite austenite austenite austenite austenite
Magnetic Property nonmagnetic nonmagnetic nonmagnetic Weak magnetic Weak magnetic


High Melting Point Corrosion Resistant Non-Magnetic Nichrome Electric Resistance Wire for Heating Elements 0
High Melting Point Corrosion Resistant Non-Magnetic Nichrome Electric Resistance Wire for Heating Elements 1
High Melting Point Corrosion Resistant Non-Magnetic Nichrome Electric Resistance Wire for Heating Elements 2
